PATTERN GLASS

Characteristics:

-CRYSTALCLEAR patterned glass is made with a rolled glass process. All rolled patterned glass begins as a batch of materials, including silica sand, soda, and lime.

Thickness:

-2.5mm 3.0mm 3.5mm 4mm 5mm

Order Hotline: sales@crystalclear-glass.com
INQUIRY

CRYSTALCLEAR patterned glass is made with a rolled glass process. All rolled patterned glass begins as a batch of materials, including silica sand, soda, and lime. These materials are melted together in a tank, and then the molten glass mixture is fed onto a machine slab. The glass flows under a refractory gate which controls glass volume and speed then moves between two counter-rotating, water-cooled rollers. One of these rollers is embossed, imprinting a distinct pattern onto the soft surface of the glass while the other roller is smooth.


The result is a piece of glass that is patterned and textured on one side, while smooth on the reverse. The distance between the two rollers determines the ultimate thickness of the glass. After it moves between the rollers, patterned glass is annealed or cooled slowly in order to remove any residual stresses. Rolled patterned glass can then be cut into standard sizes or cut into customized sizes for a specific customer application. The glass is then inventoried and ready for delivery.


Applications:

CRYSTALCLEAR pattern glass are used in commercial, residential, and specialty applications. End uses include shower doors and tub enclosures including frameless shower doors interior partitions, translucent door and window treatments, foyers and vestibules, patio furniture, shelving, decorative furniture, and lighting fixtures. Comprehensive range of soft natural colours compliments and harmonizes with modern building materials to provide an exciting and different look to new and existing buildings. Pattern glasses are available in large amount of patterns. Patterned glass is most often found in bathroom windows.


Patterned glass is applied to all kinds of public and private places, such as office, meeting room, hotel, hospital, bath room, washroom, etc. It is also widely used as glass table, glass shaft and lampshade and so on. Mainly used in interior partitions, interior design, decorations, street furniture etc.


GLASS COLOR:

Clear

Ultra Clear

Bronze

Grey

Amber

Blue

Green


GLASS DESIGN:

Nashiji, Mistlite, Glue Chip, Moru, Morgon II, Flora, Mayflower, Karatachi (Puzzle), Crystal, Aqualite, Masterlite, Chinchilla, Diamond, Rain-S, Rain-B, Wood, Millenium ect.


Thickness

Regular Sizes

Thickness

Regular Sizes

2.5mm

1524x1220mm

1830x1220mm

5.5mm

1830x2134mm

2000x2440mm

3.0mm

1830x1220mm

2134x1524mm

2134x1676mm

6mm

1830x2134mm

1830x2440mm

1860x2520mm

3.5mm

2000x1500mm

1524x2134mm

8mm

1830x2134mm

1830x2440mm

1860x2520mm

4mm

1650x2134mm

1830x2134mm

1830x2440mm

10mm

1830x2134mm

1830x2440mm

1860x2520mm

5mm

1830x2134mm

1830x2440mm

2000x2440mm

Max size

2134 x 4500mm

Special sizes

Can be produced as customer’s requirements
